Service Overview
In construction environments, poorly coordinated drawings are one of the leading causes of installation conflicts, rework, and execution delays. Coordination of Drawing Creation ensures that architectural, structural, and MEP systems are fully aligned and translated into precise, construction-ready documentation. At Desapex, we generate coordinated drawings directly from clash-resolved BIM models, ensuring spatial accuracy, service routing validation, and constructability compliance. Our approach bridges the gap between digital design and physical execution, delivering clear, fabrication-ready documentation that enhances site efficiency and minimizes ambiguity.
Our Digital-First Approach
Model-Based Extraction
Develop drawings directly from federated, clash-free BIM models.
Core Deliverables
Precise, construction-ready coordination, and MEP shop drawings generated directly from clash-resolved BIM models.
Unified layouts integrating architectural, structural, and MEP systems.
Documentation validating service routing, spatial clearances, and installation sequencing.
Drawings aligned with regional building codes and fabrication standards.
Why Choose Desapex
Desapex delivers coordination drawings that are not just digitally aligned but fully execution ready. Our engineering-led approach ensures that every drawing reflects constructability intelligence, compliance standards, and real-world site conditions. This leads to faster construction execution, minimized RFIs, and reduced installation errors.
Unique Selling Proposition
Our USP is our engineering-first documentation expertise combined with deep BIM-to-construction integration capability. Backed by a strong quality control and governance framework, we focus on delivering a measurable reduction in construction risks across complex multidisciplinary projects.
